SERVICING INTERVALS
SERVICING INSTRUCTIONS Template Name: OM_1_col Template Date: 1994_04_29
Respect the maintenance intervals by checking the hourmeter every day. Before starting maintenance, park the machine on flat, firm ground, away from any obstacles, with the dipper retracted and the tool on the ground. Unless otherwise specified, all maintenance operations must be carried out with the engine stopped, and the key removed from the starter switch. It is preferable to wait for all circuits to cool down before starting work. Clean the grease fittings before lubrication. Clean around plugs and filler holes before adding fluid. No dust or dirt must enter the components or the circuits.
TRIM THIS EDGE
!
WARNING: There is a risk of serious injury if maintenance or repairs are not performed correctly. If you do not understand the maintenance procedures, consult your CASE Dealer.
!
WARNING: the attachment is raised or if the machine moves without an operator, serious injury can result. Before performing any maintenance, the following steps must be carried out: 1. Park the machine on flat, horizontal ground. 2. Lower the attachment until it is resting on the ground. 3. Lower the dozer blade until it is resting on the ground. 4. Stop the engine and remove the starter switch key. 5. Lock the tracks to prevent any machine movement.
Alt= to hide template information Alt+ to display template information
When performing maintenance on the machine, place a “DO NOT START UP” label on the instrument panel. Never leave the operator’s compartment when the engine is running. Any modification to this machine without prior authorization could cause serious injury. Do not make any modifications without authorization. Consult your CASE Dealer. IMPORTANT: If you use your machine in particularly harsh conditions (dusty or corrosive atmosphere, etc.), the servicing intervals should be reduced accordingly. IMPORTANT: Take particular care to replace all filters regularly. Clean filters mean longer engine running life. IMPORTANT: Oil and fluid should not be thrown on the ground. They must be stored and removed by a company which is responsible for their recycling or their disposal.
78
