OPERATING INSTRUCTIONS
HANDLING THE MACHINE STEP 4 Slinging procedure Template Name: OM_1_col Template Date: 1994_04_29
STEP 1
60°
Raise the boom completely, retract the dipper completely and close the bucket. STEP 2 Place the upperstructure in line with the undercarriage, with the attachment to the front, completely raised and the dozer blade to the rear. Swing the attachment to be in line with the upperstructure.
CK98B019
Install protective pads at places where the slings may come in contact with the machine.
STEP 3
TRIM THIS EDGE
IMPORTANT: It is essential that the angle between the slings on the dozer blade and the sling on the boom is 60°.
Alt= to hide template information Alt+ to display template information
!
WARNING: The machine must be handled very slowly.
!
WARNING: Make sure that there is nobody under or near the machine while it is being handled.
!
WARNING: The machine must be handled horizontally.
CK98B019
Attach a sling to the sling point on the boom and the other two slings to the sling points at the ends of the dozer blade.
!
WARNING: It is essential that the slings are attached to the machine at these three points.
IMPORTANT: Make sure that the slings or straps are in perfect condition and can support the weight of the machine (4,600 Kg in its heaviest configuration).
