OPERATING INSTRUCTIONS
TRANSPORTING THE MACHINE Since transport by rail is subject to special regulations, consult an approved organisation.
On a trailer
!
WARNING: This machine could slip and fall from a trailer or ramp and cause serious injury. Make sure the trailer and ramps are clean. The machine should be in line with the trailer before being loaded.
Make sure you know the safety rules and regulations before transporting the machine. Make sure both trailer and machine are fitted with the right safety equipment.
Loading TRIM THIS EDGE
STEP 2
STEP 1
Alt= to hide template information Alt+ to display template information
On a railway wagon
A
CS96C044
C CS96F005
Place a block behind and in front of the truck or trailer wheels.
Place the access ramps solidly in place, placing support blocks beneath the ramps and observing dimensions (A and B) of the ramps and (C) of the space between the ramps. A length of ramps............................5,000 mm B Width of ramps ...................... 500/600 mm C Width of space between ramps 1,000 mm STEP 3 Place a support behind the rear end of the truck or trailer.
67
