CONTROLS/INSTRUMENTS/ACCESSORIES
Windshield wiper
CD98A030
CD98A033
When in the off position, always make sure that the windshield wiper is resting on the guide.
Tool box
Operator’s seat TRIM THIS EDGE
To open or close the right-hand sliding window, press the locking latch and slide the window.
CD98A016
Located under the floor mat, in front of the seat, the tool box can be used to store fast-moving parts and tools required for maintenance operations.
For correct operation of the machine with maximum efficiency and comfort, adjust the seat correctly to suit the weight and size of the operator. NOTE: The seat can only be adjusted correctly when the operator is seated in it.
49
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CK98B011
Alt= to hide template information Alt+ to display template information
Sliding window
