ELECTRICAL SYSTEM
Tools required - Auxiliary starting cables
1.
Connect the positive (+) auxiliary cable to the positive (+) terminal to the machine system.
2.
Connect the negative (-) auxiliary cable to the negative (-) terminal of the machine system.
3.
Start the engine.
4.
Disconnect the negative (-) auxiliary cable, then the positive (+) auxiliary cable from the booster battery.
ALTERNATOR Service specification Check ......................................................................................... Every 1,000 hours
!
TRIM THIS EDGE
Make sure that the booster battery has the same voltage as that of the machine (12 volts).
WARNING: Whenever carrying out a welding operation on the machine, as authorized by the manufacturer and in accordance with his instructions, or making repairs to the electrical system, disconnect the alternator B+ and D+ wires. Be sure to identify the wires correctly when reconnecting.
IMPORTANT: Do not use a steam cleaning apparatus or cleaning solvent to clean the alternator. Have the alternator checked by your CASE Dealer. NOTE: Make sure the tag covers are correctly in place.
STARTER MOTOR Service specifications Check ......................................................................................... Every 1,000 hours Have the starter motor checked by your CASE Dealer. NOTE: Make sure the tag covers are correctly in place.
141
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
!
WARNING: Connecting auxiliary cables wrongly or short-circuiting battery terminals can cause an accident. Connect auxiliary starting cables as per the following instructions.
Alt= to hide template information Alt+ to display template information
CONNECTING A BOOSTER BATTERY
