LUBRICATION/FILTERS/FLUIDS
Template Name: OM_1_col Template Date: 1994_04_29
REMOVING WATER FROM THE WATER SEPARATOR FILTER AND REPLACEMENT OF THE FILTER ELEMENT Removing water from Replacing the filter water filter separator element STEP 1
STEP 1
TRIM THIS EDGE
CD98A015
Water must be removed from the water separator element when the warning lamp on the instrument panel comes on.
CD98A054
Remove the detector. Using the filter wrench, remove the element. STEP 2
STEP 2
Alt= to hide template information Alt+ to display template information
PH08325 CK98B031
Open the water separator water drain valve. Operate the pump about 7 times to remove the water from the filter and close the valve.
Apply a fine coating of oil or grease to the new element seal. NOTE: Do not fill the new element with fuel before installing it.
100
