1850K
73
EVERY 1000 HOURS WORK
23. BEVEL GEAR STEERING AND BRAKES Change oil and wash suction filter
ENGINE:
Drain oil
21. FUEL INJECTORS Calibrate setting of injectors
Place a container of at least 50 liter (13 USG) capacity under the transmission housing. Remove plug A and let the oil drain completely.
DANGER
Retighten plug A after washing it.
Keep hands away from the tip of injectors, when checking efficiency. Fine sprayed fuel under pressure could penetrate the skin and cause blood poisoning. Also, when checking the efficiency of injectors, wear safety glasses with side shields.
A
Have the injectors checked by a Service specialized shop.
22. VALVE CLEARANCE Check valve clearance, with cold engine Have the clearance between engine valves and rocker arms checked by specialized personnel. The adjustment of the valve clearance must be done with cold engine. Valve clearance - Intake ..................................... 0.30 mm (0.012 in) - Exhaust .................................. 0.60 mm (0.024 in)
1850-2M0133
A. Steering and brakes oil draining plug.
Wash the suction filter and magnetic rod Tilt the cab, remove plug 1 and pull-out the mesh filter indicated in the figure and the magnetic rod 5. Wash both of them with solvent. Clean inside the body. Re-install the filter, magnetic rod and cover. Check and top-off the oil after changing it.
1 2
4
3 5 F 1850-2M0132
Valve clearance check 1850-2M0134
F. Transmission/torque converter suction filter - 1. Nut 2. Cover - 3. Gasket - 4. Mesh filter - 5. Magnetic rod.
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
