1187B Crawler Logger
INJECTION PUMP DRIVE 504BOT DIESEL ENGINE REF. PART NO. 1 REF
2 2 3 4
5 5 8 9
10 12 13
14 15
16
A59077 A142092 A57470 193-68 25-106 25-126 A58693 113-207 492-11038 A62542 A58690 A58691 AS8692 113-440
Rae 8-2841
DESCRIPTION REQD PUMP ASSEMBLY - fuel injection (See Page 3-73)."." " ., .,... ,," 1 STUD - pump mounting, 3/8 NC x 1-7/8 inch (Without hole) " , .. " "",,3 STUD - pump mounting, 3/8 NC x1-7/8 inch (With hole for anti-tamper wire) 1 WASHER - 3/8 x 11/16 x 16 gaugs .. " " ........ ..... .. ....... " ..... ,.......... ......... " 4 WASHER - internal shakeproof, 3/8 inch .. .................. ., .. " ... .. ... ......... ,..4 NUT - hex, 3/8 inch NC (Used with AS9077 stud) ,.... ", .. ." ..... .. .. ............ 3 NUT - slotted, 3/8 inch NC (Used with A142092 stud) .............. ,....... ,.... 1 GEAR - injection pump drive .......... ,......... ,..... ,............. ............. .............. 1 BOLT - gear to hub, hex, 3/8 NC x 1 inch .... ............. ' ........ ' ... " .. .... " .... " 3 WASHER - lock, 3/8 inch ....... " .................................................. " .. ..... ,3 GEAR ASSEMBLY -idler, with bushing .... " ....... ,... .. .. " ................. .. ......... 1 SHAFT - idler gear ....... ................ "..... .... ......... .." .. ............. " " ........ 1 WASHER - thrust, idler shafi ................. ................ ... .... " """.,, ........... .... 1 PLATE - thrust, Idler shaft... ....................... ..................... ....... " ........ ....... . 1 BOLT - idler gear, hex, 1/2 NC x 4-1 /2 inch ..... ............. ........ ... ........ ...... 1
Issued October, 1988
Printed in U,SA
