11878 Crawler Logger
FUEL FILTEA SYSTEM 504BDT Engine REF. 1 2 3
4
5 6 7 8 9 10 11 15 16 17
18 19 20 21 22 23 24 25 26 27 28 29 30
PART NO. A155489 221-849 A20663 A146368 413-620 492-11038 A44068 NSS G49080 A28090 NSS NSS REF A65564 A20539 221-849 A157329 222-45 222-103 222-113 A64856 113-262 492-11038 A62209 113-3 193-8 192-19 25-104
DESCRIPTION REQD. HEAD ASSEMBLY - fuel fi lter """, ." .. " ... .. " ... " .... " .. ""." .... " .. " ... " « " " , , . « 1 PLUG· pipe, hex socket head, 1/8 inch PL .... " ... " ... "" .... ,,, .. .. ..... ,, .. 1 SCREW - bleed .. . " ....... " .... " .... " .. "«,, .. " ................ " ... " ............. " ... " .. " .. 2 GASKET - washer, bleed screw 2 BOLT - hex, 3/8 NC x 1-1/4 inch "" ... " .. " .... " ....... "" ..................... " .... 2 WASHER· lock, 3/8 inch .. "" .. " ...... ........... ,,, ......... ,, ....... .... ,, ........... 2 KIT - replacement, fuel filter " ......... ,............... " .. " .. .. .... ... .. " .......... " .... 1 ELEMENT - first stage fi lter (Order A44068)." .... .. ." ....... ..... " ..... "".,," 1 PLUG - drain, plastic " .. " .. " .. " ..... " ... " .... ....... .. "." ..... .. ........ " .. .. ... . 1 O-RING - 7/16 inch. " .... .... ..... " ...... " .. .. .. " ... ....... ,." .. ..... " .. ... .... ........ 1 ELEMENT - second stage filter (Order A44068) ... ...... .. ... .. ... ............ 1 GASKET· element to head (Order A44068)(See Note) " ................ 1 PUMP ASSEMBLY· fuel injection (See Page 3-73) ..... .... "." ........ ........ " 1 HOSE· filter head to pump ...... .. ... .... .................. .. .... " .. " .. " .. " ... .. " " " ... 1 UNION - hose to pump ........................................................... ,.......... " ... 1 PLUG - pipe, square head, 1/8 inch PT." ................ .. ..... " ..... ....... " .... 1 TUBE - transfer pump to filter head .... ...... " ................. " ..... " ..... " ........ 1 ELBOW ASSEMBLY - tube, 90 degree, 5/16 x 1/4 inch PI.. .... .............. 2 SLEEVE - tube, 5/ 16 inch ...... " .......... ...... " ............... ..... ........ ..... .. ,. .. 1 NUT· tube, 5/1 6 inch .. .. .... .. " .... ..... ....... .......... ..... " ... " ..... " .. " ... ......... 1 BRACKET· tube to block ............ " ..... ................. ,........... " .............. ........ 1 BOLT - hex, 3/8 NC x 5/8 inch ...... " ...................... " .. .............. .. ,........... .. 1 WASHER - lock, 3(8 inch ... " ..... .............. " .... . ............... .. .. .... .. ............ 1 CLAMP - tube to bracket ." ... " ........... ... .. ............. .............. " ......... " .... ..... 1 BOLT - hex, 1/4 NC x 3/4 inch ............ " ... .. .. .. .... " .... " ' ........ ."',, ........... ,,. 1 WASHER· external shakeproof, 1/4 inch ........................... .. .......... " ....... 1 WASHER· lock, 1/4 inch .. .. .. ... ' ...... .... .......................... .......................... 1 NUT - hex, 1/4 inch NC ........... " .... " ................ ...... ,.... ............................. 1 "« ... .... "
......... "
.........
. . . . . . . . . . . . . . . . . . . . . . . . ,,
NOTE: Whenever filter is removed , gasket must also be removed replaced with
Rae 8-2841
a new gasket.
Issued October, 1988
Printed in U.S.A.
