FUEL INJECTION SYSTEM 5048DT Engine REF, PART NO, REF
1
2 3 4 5 6 7
A156885 A156886 A156887 A156888 A156889 A156890
8 9
A58709 A58708
10 11
A58710
12 13
17 18 23 26 27
28 29
30 31
163-19 131-612 47-37 222-101 222-111 REF A76642
A76641 A153816 AS9097 222-102 222-112
Rac 8·2841
DESCRIPTION REQD. PUMP ASSEMBLY - fuel injection (See Page 3-73) ... .. .. ....... .. ... " .. " .... ". 1 TUBE - fuel injection, No.1 cylindeL .. ,., ............... ,.. ... " .. ,... " ...... 1 TUBE - fuel injection, No, 2 cylinder ................. .. .......... .... .. ............ " ... " 1 TUBE - fuel injection, No.3 cylinder .. ." .. . " ... " .......... " ... " ... " ... " .. " ....... 1 TUBE - fuel injection, NO.4 cyHnder .. .... " .. ,. ....... " .... ,.. , .. ... ....... ..... " .... 1 TUBE· fuel injection, NO.5 cylinder ......................... " ...... .. ...... ...... ... .. .. 1 TUBE - fuel injection, NO.6 cy!inder " ...... ' ......................................... 1 BRACKET - injection tube .. .... ..........." ........................... " ............. " ...... 14 PLATE - injection tube bracket (For S lines) ....... .. .. " .. """ " ... " .. .", .... 1 PLATE - injection tube bracket (For 4 lines) ." ." ... .. .. ... " ..... .. ............ ... 1 SCREW - hex slotted, No, 10 NC x 1 inch ..... .................................... .... 7 NUT - Tinnerman, No. 10 NC ........ " ........ "" .......... .. ............. " .. " ....... 7 RIVET· flat head, 3/16 x 7/16 inch ................................. .................... .... 1 SLEEVE - for 3/16 inch tube. . ............... .. ... .. ...... ..... ..... .. ... ..... .. ..... 12 NUT - for 3/16 inch tu be ................ .................... " .... .. .............. .. .. .. ..... 12 NOZZLE ASSEMBLY - fuel injection (See Pages 3-75 and 3-77) .......... 6 TUBE - leak-off, 4-11116 inch long .. ... .. 3 TUBE - leak-off, 5-3/4 inchlong ... " ...... . ...... .. ........... ... .... .. .................. 2 TUBE· leak-off, No.1 nozzle to valve .. ..... .. ...... 1 VALVE ASSEMBLY - check, leak-off (in injection pump) ... .. .... .. ...... " .... 1 SLEEVE- for 1/4 inch tube .......... " ........... " ... .. " ...................... ..... ......... 2 NUT - for 1/4 inch tube .. ..................... ... ... ....... ... .... ............................ 2 ><
»
