1187B Crawler Logger
4·97
CASE ENGINE ELECTRICAL SYSTEM USED ON MODELS PRIOR TO PJ.N. 6275525 REF. PART NO.
192-19 129-101 S618794 S107265 S99513 S63884 S242609 217-1084 S108396 * S119471 S240588 195-518 131-71 S237284 L1 8337 R14668 113-102 192-20 113-206 192-21 * S118377
LOOM - bulk roll, 240 " (6096 mm) long .. .. .. .... ................... UAR
REF
2 3 4
113-421 11 3-427 192-23 196-15 S229640 113-207 192-21
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
REO 'D.
STARTER ASSEMBLY - engine, see pages 4-85 through 4-91 for correct starter and parts list ....• .. ...••......•.••...•.•..•............•. 1 BOLT - hex head, 1/2" - 13 NC x 2", starter mounting ...•..• ....• . ...... 2 BOLT - hex head, 1/2" - 13 NC x 3-1/41<, starter mounting .•..•... .. . ...•. 1 WASHER -lock, 1/2", starter mounting •........•.•.... .. . ....... .. .•. 3 WASHER· flat, 1/2 ", starter mounting . .. ....•.... •.•..... • ..........• 3 CABLE - ground, starter to engine and engine to turntable ........•..•.... 2 BOLT - hex head, 3/8 It - 16 NC x 1 II, ground cable to engine .•.........•.. 1 WASHER . lock, 3/8 ground cable to engine .•.•.•..•..•...••••.....•. 1 WASHER - flat, 3/8", ground cable to engine and frame ....•••..•.....•.. 3 NUT - hex, self-locking, 3/8 " - 16 NC, ground cable to turntable .••..•....•. 1 AL TERNATOR ASSEMBLY - parts list pages 4-81 and 4-83, mounting brackets page 4-95 •. . •. . •....... .... .• ...•.......•.••.........• •.....•• 1 WASHER -lock, 1/4", alternator output terminal .. .. ••..... ... ....•.•..• 1 NUT - hex, 1/4" - 20 NC, alternator output terminal •...•..••...•......... 1 HARNESS - engine •.... .•... ...• ...•.•... • , .. .................... 1 CONNECTOR - harness .....• , ...•.....••..••..••......•.•....... 1 CONTACT - connector, female, not shown ..•..•..•..•••.•..... , .•• 8 SWITCH· hourmeter, oil pressure activated. . • . • • • . . • • • . . • . . . . . . . • . . • .. 1 SENDER - engine oil pressure .....•.......•••.•.•...•.•...••.....•. 1 ELBOW - 45 degree, 1/8 " NPT ....•..••..•...•...•...•••......... , " 1 SENDER - engine temperature • . ...••.• .•.... ..•..... ...... ••.....•. 1 LOOM - 24" (610 mm) long, sender wire, cut from S118377, see below ...• " 1 RELAY - starter ..•.•...•....••..•......••••.•.....•......... ,.... 1 WASHER - flat, 1/4", relay mounting ..•....••.•..•..•................ 2 NUT - hex, self-locking, 1/4" - 20 NC, relay mounting ......••.. • . ....•.•. 2 RESISTOR· alternator circuit ....•.......•...•..••....•.....•....... 1 STRAP - tie, harness •..•..•.. •• .....•. ...•...•.....•....•..•... UAR CLAMP - harness ....••.•......•..•...•.............•..•..•....•.. 3 BOLT - hex head, 5/16 " - 18 NC x 3/4 " ..•..•...•......••...•••....... 1 WASHER -lock, 5/16 " ......• ... ..•...•...••.. ...•..• .••••....• , .. 1 BOLT - hex head, 3/8 " - 16 NC x 3/4 " . ...... , ..... ................... 1 WASHER - lock, 3/8 " •......• .. ..••......... ... ..• .. • . •..•.....••• 1
1
5
DESCRIPTION
195~525
131-52 REF
Bur 8-2841
11
,
Issued October, 1988
Printed in U,S.A.
