STOPPING THE ENGINE AND LEAVING THE EXCAVATOR Procedure Figure 91
Figure 93 ON STOP
START
P113576
Turn the switch to STOP [Figure 93]. Disconnect the seat belt. Remove the key from the switch (If Equipped) to prevent operation of machine by unauthorized personnel. Raise the control console and exit the machine.
Figure 92
1
P113405A
Move the engine speed control lever (Item 1) [Figure 92] back to low idle. Run the engine at idle speed for about 5 minutes to allow it to cool.
73 75 of 178
E19 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
7186708A
Expand the tracks fully. Stop the machine on level ground. Lower the work equipment and the blade to the ground [Figure 91].
