MONITORING THE DISPLAY PANELS Instrument Panel
Warning And Shutdown
Figure 90
When a WARNING condition exists; the associated icon light is ON and the alarm sounds 3 beeps. If this condition is allowed to continue, there may be damage to the engine or hydraulic systems. When a SHUTDOWN condition exists; the associated icon light is ON and the alarm sounds continuously. The monitoring system will automatically stop the engine in 15 seconds. The engine can be restarted to move or relocate the excavator.
2 1
The SHUTDOWN feature is associated with the following icons:
NA3172
General Warning Engine Malfunction Engine Coolant Temperature
Frequently monitor the temperature and fuel gauges [Figure 90].
Dealer Copy -- Not for Resale
After the engine is running, frequently monitor the instrument panel [Figure 90] for machine condition. The associated icon is displayed if there is an error condition. EXAMPLE: Engine Coolant Temperature is High. The Engine Coolant [Figure 90] is ON.
Temperature
icon
(Item
1)
Press the Information button (Item 2) [Figure 90] repeatedly to cycle the data display until the service code screen is displayed. One of the following SERVICE CODES is displayed. •
[M0810] Engine Coolant Temperature Too High
•
[M0811] Engine Coolant Temperature Extremely High
Find the cause of the service code and correct before operating the excavator again. (See DIAGNOSTIC SERVICE CODES on Page 147.)
72 74 of 178
E19 Operation & Maintenance Manual
