Repair instructions
Final assembly
884830 1
1. Dismantle pinion and gear and clean parts from marking dye and then assemble with the calculated shims. Then install the spacer ring, the locking ring and the nut on the vertical shaft. Tighten the nut and lock with the locking washer. Use special tool 884830 as a counter hold.
3. Install the O-rings (1) in the propeller bearing housing. Coat the contact surfaces and the screws with sealing compound, Volvo Penta part no. 1161099-5 or Permatex® no. 3. Install the propeller bearing housing in the gear housing and tighten the 2 Allen-head screws. NOTE! Turn the vertical shaft somewhat to allow the gears to engage. Tightening torque 40 Nm (29.5 lb.ft.).
1
2. Tighten the pinion nut with a torque of 160 Nm (118 lb.ft.). Then lock the nut with the locking washer (1). Use special tool 884830 applied at the splines shaft end as a counter hold.
98
