Assembly Adjustment (Traveling Device) 4. Tire air pressure and steering angle adjustment 4.1 Adjusting the steering angle [NOTICE] Tire size : 385/95 R 25 170E kPa {9.00 Air pressure : 900
kgf/cm2} (130.5
psi)
1. Jack up the vehicle and select 4-wheel steering mode. Turn the steering wheel 2 to 3 times to bleed the steering cylinders. 2. Before adjusting the steering angle, use a side-slip tester to check that the amount of tire side-slip is within 3 mm (0.12 in) for both the front and rear tires. 3. If it is out of 3 mm (0.12 in), loosen the bolts that fasten the left and right tie-rod ends. Then rotate the tie-rod and adjust the toe-in. 4. Jack up the vehicle on the level surface (so that the height of the left and right tires is the same). Use the steering angle measuring jig to adjust the steering angle in direction A to 35° ° using stopper bolt A, and the one in direction B to 35° ° using stopper bolt B. 5. Perform the same adjustment for the rear wheels.
42
WY05-3580E
