5. Dual screens system(FB5844--) 5.1 General description This is an device of switching control of multiple camera images. And it displays dividing images of L/R camera or / camera between dual screens. It provides following function; Power supplying to the camera (2 systems); Image I/O (2 systems of camera input and 1 system of image output); Switching images of the camera. By connecting with 6.5″ LCD monitor (CJ981), monitor unit(EA1246), and CCD camera (CC1031A), it is possible to confirm safety around the vehicle with dual screens.
5.2 Feature 1. This system has each inputs from 2 cameras. It can display each of inputs on a screen or display both inputs on a divided dual screen. 2. By using special wired remote controller (selection switch), you can select “Left (L)” or “2” camera image, you can select “Right (R)” or “1” camera image on a screen, or you can select “Left (L) + Right (R)” or “2 + 1” on a dual screen. 3. For changing character display selection according to a position of camera mounted, you can select “Left (L) / Right (R)” when you ground the character display terminal of the harness. When you open the terminal, you can select “2 / 1”. Charaher display Charaher Camera image Screen display selection terminal display display screen Left (L)
GND Left(L) or 2
2
OPEN
Left (L)
Selection switch
Left (L)+ Right (R) or 2+1
Right (R)
GND
2
2 (Upper right on displry) Left (L) (Upper left of center) Right (R)(Upper right of center) 2 (Upper left of center) 1 (Upper right of center)
1
OPEN
Right (R)
Right (R) (Upper left on displry)
GND Right (R) or 1
Left (L) (Upper right on displry)
1
1 (Upper left on displry)
OPEN
Left (L) camera or 2 camera
Left (L)+Right (R) camera dual screens or 2+1 camera dual screens
Right (R) camera or 1 camera
4. For selection “ON / OFF” of the timer function (shutting down camera screen), you can select “ON” when you ground “timer control ON / OFF terminal”. When you open the terminal, you can select “OFF”. 5. Supply voltage of this system is DC12V specification. When you use together with EA1246, by connecting with DC12V supply harness, you can use this system on the DC24V specification machine.
