Functions of and How to Use User Mode (TL-300E-3) Selecting Lift Status [NOTICE] The boom lift status is the default status and is automatically selected (the boom lift symbol lights up) when the power supply is turned on (the PTO switch is placed in the ON position). Turning the power off (PTO switch: OFF) automatically erases all the previous settings stored in memory after approximately 2 hours. To resume the operation more than 2 hours after the power has been last turned off, enter the settings all over again. Register the lift status using the lift mode select key and the register key.
Each time the lift mode select key is pressed, the status changes in numerical sequence, from (1) to (9), as shown below. The display returns to (1) if you press the switch when status (9) is shown on the display. Select the status that corresponds to the actual lift status. [NOTICE] !After making sure that the display conforms to the actual lift status, press the register key. The corresponding lift indicative symbol will change from flashing to continuous lighting, and the moment display, rated lifting capacity display and actual load display will return to normal display conditions, meaning that the status has been registered. (When the jib set status is selected, the jib lift symbol will remain flashing.) !Select the boom lift status when lifting a load on the boom with the jib mounted.
[NOTICE] !Select a jib lift status when lifting a single load using both the boom and jib.
25
W301-0351E
