Functions of and How to Use User Mode (TL-300E-3)
19. Boom angle display
15. Lifting height limit symbol
Normally displays the boom angle. Displays the moment ratio when the display alteration key is pressed. When a lower boom angle limit has been registered, the registered lower boom angle limit value is displayed while the register key is pressed.
This symbol indicates that the boom length display [13] is showing the registered lifting height limit value. The lifting height symbol [14] is also displayed at the same time. 16. Upper boom angle limit symbol This symbol indicates that the jib angle display [1] is showing the registered upper boom angle limit value.
20. Boom lift symbol This symbol indicates that the boom lift is selected.
17. Boom angle symbol This symbol indicates that the boom angle display [19] is showing the boom angle.
21. Single top lift symbol This symbol indicates that the Single top lift is selected.
18. Lower boom angle limit symbol This symbol indicates that the boom angle display [19] is showing the registered lower boom angle limit value.
20
W301-0351E
