Brake Fluid Reservoir Checking Brake Fluid Reservoir Level 1. Perform the “Mandatory Safety Shutdown Procedure” on page 8. 2. Open the engine hood. 3. The brake fluid reservoir (1, Figure 95) is located against the operator 2 platform at the front of the engine compartment. 4. Carefully remove the brake fluid reservoir fill cap (2, Figure 95). Be care1 ful not to allow dirt to fall into the reservoir. 5. The brake fluid reservoir fluid level should not fall below 1/2 full. Add automatic transmission fluid as Figure 95 – Brake Fluid Reserrequired. voir
Wheels and Tires
1. Brake Fluid Reservoir 2. Brake Fluid Reservoir Cap
Wheel Fasteners Wheel fastener torque must be checked before initial operation and every day thereafter until the wheel mounting hardware torque stabilizes. Torque the wheel fasteners in the order shown (Figure 96). When tires are removed and replaced, this procedure must be repeated. See “Wheels” on page 31 for wheel fastener torque specifications, wheel rim dimensions and wheel offset measurements.
1 3 6
5 4 2 Figure 96 – Wheel Fasteners Tightening Order (AL500 Series model shown)
