Fuse Panel - Steering Column 12
11
10
13
9
14
8
7
15
6
5
16
4
3
2
1
TOP
Figure 103 – Fuse Panel, Steering Column Fuse No. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16.
Rated Current (Amp)
5 10 5 7.5 5 10 5 10 20 10 10 7.5 10 10 5 10
918444/AP0210
Protected Circuit
Instrument panel, differential lock, cab relay Joystick, control module relay Fuel pump, fuel solenoid hold Horn, beacon Work light switch, work light relays Power-A-Tach® Starter relay Turn signals Ignition switch Rear work light Front work light 12-V accessory power outlet High-beam headlights Low-beam headlights Position lights Spare fuse
