TECHNICAL DATA DIMENSIONS
Max. Length Max. Width Max. height Seat height Wheelbase Minimum ground clearance Weight in running order
2195 mm 870 mm 1125 mm 800 mm 1495 mm 185 mm 248 kg
ENGINE
Model Type Number of cylinders Displacement
Compression ratio Starting Engine idling rpm Clutch Lubrication system Air filter Cooling
Breva V 850 IE - Breva V 1100 IE 90° traverse V-type, twin-cylinder, 4-stroke 2 877 cc 850 1064 cc 1100 92x66 mm 850 92x80 mm 1100 9.8: 1 electric 1100 Ø 100 rpm twin-plate, dry pressure-fed system, adjustment through valves and gear pump cartridge, dry air
GEARBOX
Type
mechanical, 6 gears with foot control on the left side of the engine
CAPACITIES
Fuel (reserve included) Fuel reserve Engine oil Gearbox fluid Transmission fluid Fork fluid Seats Max vehicle load
23 b 4b oil and oil filter change 3600 cc 500 cc 380 cc 400 Ø 2.5 cu cm (per leg) 2 230 kg (rider + passenger + luggage)
Bore / stroke
90
