1
2
5
3
CAUTION Before changing a bulb, move the ignition switch to position “ ” and wait a few minutes, so that the bulb cools down. Wear clean gloves or use a clean, dry cloth to handle the new bulb. Do not put your fingerprints on the bulb, as this may lead to overheating and failure. If you have handled the bulb with bare hands, clean it with alcohol to avoid any damage. DO NOT PULL ON THE WIRES.
NOTE
Before changing a bulb, check the fuses, see page 79 (CHANGING THE FUSES).
CHANGING THE HEADLIGHT BULBS Carefully read page 82 (BULBS). The headlight houses: √ one high beam bulb (lower). √ one low beam bulb (upper); √ one parking light bulb (lower); To change oil: u Place the vehicle on the stand, see page 55 (PUTTING THE VEHICLE ON THE STAND). Applies to high and low beam bulbs only. u Remove the two side screws (1) to remove the headlight. u Remove the cover (2), push it up, release it from lower tab and slide out the top tang from its seat.
6
4
HIGH BEAM BULB Do not pull on the wires to extract the bulb connector. u Disconnect the connector (3). u Turn the ring nut counter clockwise and
remove the bulb body (4). u Change with a new one. u Refit the bulb body in the housing and
turn clockwise until it locks in place. u Connect the connector (3).
use and maintenance Breva
83
