BEAM VERTICAL ADJUSTMENT u Place the vehicle upright. u Adjust headlight beam, turn screw (2). When finished:
WARNING Check for correct beam horizontal setting.
BEAM HORIZONTAL ADJUSTMENT u Place the vehicle on the stand, see page 55 (PUTTING THE VEHICLE ON THE STAND). u Remove the two screws (1) (one each side). u Hold the light up and turn screw (3) to set the beam. u Refit the light and start both screws (1) in their thread and check for beam correct setting. u If it is correct, tighten both screws (1). When finished:
WARNING Check for correct beam vertical setting.
