GUZum_breva1100#06_##uk.book Page 79 Wednesday, March 8, 2006 6:14 PM
2
1 4
3 3 4
u Clean the switch if caked with dirt or
mud. The pin must move freely and return automatically to its initial position. u Make sure that the cables are connected correctly.
CHANGING THE FUSES Carefully read (MAINTENANCE).
page
57
CAUTION Do not repair faulty fuses. Never use a fuse of a rating other than specified. This could damage the electric system or cause a short circuit, with the risk of fire.
In this case it is advisable to contact a Moto Guzzi Authorised Dealer. Checking the fuses is recommended whenever an electric component fails to operate or is malfunctioning, or when the engine does not start. First check auxiliary fuses (2), ABS fuses (3) ABS and then main fuses (4).
NOTE
If a fuse blows repeatedly, there might be a short circuit or an overload in the electric system.
use and maintenance Breva
79
