u Make sure that the cable terminals and
the battery terminals are: √ in good condition (and not corroded or covered with deposits); √ covered with neutral grease or Vaseline.
If necessary:
REMOVING THE BATTERY
u Remove the battery, see (REMOVING
THE BATTERY), in this page. u Clean off cable and battery terminals
with a wire brush to remove all traces of corrosion. u Install the battery, see page 78 (INSTALLING THE BATTERY).
CAUTION Removing the battery resets the following functions: digital clock, trip info and lap times. To re-set these functions, see page 17 (MULTIFUNCTION LCD DISPLAY). Carefully read page 75 (BATTERY). u Make sure that the ignition switch is in
position ≈
∆.
u Remove the rider seat, see page 29
(UNLOCKING/LOCKING THE SEAT). u Loosen the two screws (1) and move
aside the cover (2).
