1,5 mm 1
1
2
2 1
1
3 CHECKING THE BRAKE PADS FOR WEAR Carefully read page 33 (BRAKE FLUID recommendations), page 34 (DISC BRAKES) and page 57 (MAINTENANCE).
NOTE
The following information applies to both braking systems.
NOTE
Halve maintenance intervals if you are riding in rainy or dusty conditions, on rough road surfaces or when the vehicle is used in competitions. Check the brake pads for wear after the first 1000 km (625 mi), every 2000 km (1250 mi) afterwards and before each ride. The rate at which brake pads will wear depends on vehicle usage, riding style and road surface condition.
70
use and maintenance Breva
WARNING Check the brake pads for wear, possibly before each ride.
Z
Outlined below is a quick brake pad inspection procedure: u Place the vehicle on the stand, see page
55 (PUTTING THE VEHICLE ON THE STAND). u Visually inspect the area between brake disc and brake pads proceeding as follows: √ look from above at the rear to check the front brake calliper (1); √ on vehicle opposite side, through the rim, to check the rear brake calliper (2).
4
1,5 mm
WARNING If brake pads were allowed to wear down to the metal substrate, metal-tometal contact with the brake disc would lead to rattling and the brake calliper sparking; this would result in loss of braking and brake disc damage, leading to a dangerous riding condition. When the lining material of any one of the brake pads [whether front (3) or rear (4)] is worn down to nearly 1.5 mm, or when one of the wear indicators is worn away, have all brake pads changed.
WARNING To have them replaced, contact your Moto Guzzi Authorised Dealer.
