3 PUTTING THE VEHICLE ON THE STAND SIDE STAND To put the vehicle on the side stand while seated astride the vehicle, see page 44 (GETTING ON AND OFF THE VEHICLE). If you have folded up the stand (say, to wheel the vehicle forward or backward), put the vehicle back on the stand as follows:
WARNING Make sure the ground is firm and level and free from obstacles. u Select
an appropriate location for parking, see page 54 (PARKING). u Grasp the left grip (1) and place your right hand on the rear upper part of the vehicle (2).
u Push on the side stand with your right
foot and lower it completely (3). u Lean the vehicle to the side until the stand is resting on the ground. u Rotate the handlebar fully to the left.
WARNING
CENTRE STAND
WARNING It is forbidden to position the vehicle on the centre stand when sitting astride the vehicle.
WARNING
Make sure that the vehicle is stable.
Make sure the ground is firm and level and free from obstacles. u Select
an appropriate location for parking, see page 54 (PARKING). u Grab the left handgrip (1) and handle (4).
CAUTION For your safety, the side stand down condition is indicated to avoid vehicle tipping over.
use and maintenance Breva
55
