1
u Make sure that the dimmer switch (1) is
2
in position "
".
u Set the engine stop switch (2) to position
"
".
u Turn the key (4) and set the ignition
switch to position "
3 4 5
Do not start the engine in an enclosed space or poorly ventilated area.
STARTING
WARNING This is a high-performance vehicle. We recommend that you become familiar with it gradually using the greatest care. Do not store any objects on the inside of the headlight fairing (between the handlebar and the instrument panel) as this could impair handlebar movement or hide the instrument panel from your vision.
NOTE
Before starting the engine, carefully read section "Safe Riding", see page 5 (SAFE RIDING).
WARNING Exhaust gases contain carbon monoxide, which is extremely toxic if inhaled. 48
use and maintenance Breva
Failure to observe this warning may lead to loss of consciousness or even death by asphyxia.
NOTE
With the side stand down, the engine can be started only if the gear is in neutral; if you attempt to engage a gear with the stand down, the engine will stop.
With the side stand up, you can start the engine in neutral or with a gear engaged and the clutch lever pulled in. u Sit astride the vehicle, see page 44 (GETTING ON AND OFF THE VEHICLE). u Make sure the stand is fully up.
".
The following occurs: √ the parking lights come on; √ all warning lights on the instrument panel come on; √ the LCD will show "Moto Guzzi" wording for 2 seconds; √ the speed indicator and fuel gauge indexes reach end of scale, rpm index moves to max. set value; √ as soon as the first check routine is over, the warning lights go off, the instruments indicate the current value and the LCD displays the configuration set on the selector; √ the fuel pump puts the feed circuit under pressure and hums for approximately three seconds.
CAUTION If the low fuel warning light " " (5) on the instrument panel comes on, it means that there are 4 litres of fuel left in the tank. Refuel as soon as possible, see page 32 (FUEL).
