CLUTCH
NOTE
Halve maintenance intervals if you are riding in rainy or dusty conditions, on rough road surfaces or when the vehicle is used in competitions.
1
Every 10000 km (6250 mi) have the clutch inspected by a Moto Guzzi Authorised Dealer.
The clutch reservoir is located on the left handlebar, close to the clutch lever fitting.
NOTE
Halve maintenance intervals if you are riding in rainy or dusty conditions, on rough road surfaces or when the vehicle is used in competitions. Before leaving, check the fluid level in the reservoir, see page 39 (CLUTCH), have it changed every two years by a Moto Guzzi Authorised Dealer.
WARNING Do not ride if the clutch hydraulic circuit is leaking.
CHECK u Place the vehicle on the stand, see page 55 (PUTTING THE VEHICLE ON THE STAND). u Turn the handlebar partially to the right, so that the fluid inside the clutch reservoir is parallel to the reservoir edge (1) (see figure). u Make sure that the fluid level exceeds the "MIN" mark. u MIN= minimum level u Top up if the fluid does not reach at least the ≈MIN∆ mark. TOPPING UP Carefully read page 38 (CLUTCH FLUID - recommendations).
