The tool kit includes: √ √ √ √ √ √
3, 4, 5, 6 mm bent Allen spanners (1); 8 - 10 mm double fork spanner (2); 13 - 14 mm double fork spanner (3); 19 mm fork spanner (4); 8 - 10 mm socket spanner (5); 17-21 mm socket spanner for spark plug (6) and fork preload adjustment; √ double-ended cross-head/flat-blade screwdriver (7); √ pliers (8) √ tool box (9).
2
3
1 4
10 5
Maximum allowed weight: 5 kg inside the glove compartment + 5 kg inside the tool kit compartment.
LUGGAGE ANCHOR POINTS A small piece of luggage can be fitted on the seat rear end; it can be positioned using elastic bands to be secured to the 4 elements (2 each side) (10). Maximum allowed weight: 5 kg.
6 8 7
WARNING Carry small luggage only and make sure it is fastened securely.
9
30
use and maintenance Breva
