A F B
2
E 1
C 5
MULTIFUNCTION LCD DISPLAY CONTROLS 1) Switch with three positions: TRIP1 / TRIP2 / MODE 2) SET push-button; press briefly to scroll functions available inside MENUs, press longer to confirm selection. Turn the key to " ", the display will show the starting page with "Moto Guzzi" wording for 2 seconds. The display will carry out a starting check routine and then display the configuration set for switch (1).
D
3
4
Available configurations are: √ TRIP 1 √ TRIP 2 √ MODE The display always shows these data: √ CLOCK (zone A) √ AMBIENT TEMPERATURE (zone B) (when temperature is below 3° C (37° F), the ice icon " " is displayed below the value) √ Displayed configuration (zone F) (TRIP 1, TRIP 2 or MODE). The other areas show specific information. TRIP 1 AND 2 In TRIP1 and 2 the data concerning trip 1 and 2 are shown. To select TRIP 1 or TRIP 2:
u Position
switch (1) in the position corresponding to TRIP configuration to be displayed. At the bottom of the display, in zone C, the ODOMETER is displayed, regardless of the selected TRIP. The active configuration is shown in zone F, centre zone D always shows the partial distance covered, while zone E can show the following data: √ TRIP TIME; √ FUEL CONSUMPTION; √ INSTANT FUEL CONSUMPTION; √ MAXIMUM SPEED; √ AVERAGE SPEED; Data can be selected in a sequence by briefly pressing the SET(2) push-button. To reset all the trip values for the selected TRIP u press the SET (2) push-button for several seconds.
use and maintenance Breva
17
