INSTRUMENTS AND INDICATORS TABLE Description
Function
Direction indicator LED (
Flashes when the relevant direction indicator is on and all at the same time when the emergency button is activated
)
ABS LED (Anti-lock Braking System) Carries out the ABS system check routine. After the key is turned on, it stays on until speed is above 5 km/h, ( ) (Only for vehicles equipped with then turns off. Turns on in case of faults. Should the light come on during engine normal operation, the ABS is automatically disabled, because ABS) this means that there is a failure in the ABS system. Should this be the case, contact a Moto Guzzi Authorised Dealer as soon as possible. ABS
It indicates alarms for engine oil pressure, fuel electronic injection and immobilizer. If LED " ! " stays on after the engine is started or comes on during normal CAUTION engine operation, it means that the electronic control unit has detected a failure; immediately contact a Moto Guzzi Authorised Dealer. If this comes on and the icon " " appears on the multifunction display, this means that the engine oil pressure in the circuit is low. If so, stop the engine immediately and contact a Moto Guzzi Authorised Dealer.
Alarm LED ( ! )
Neutral indicator LED (
)
Turns on when gearbox is in neutral
Side stand down LED (
)
Turns on when the side stand is down.
High beam LED ( Fuel reserve light (
Comes on when the headlight high beam is on or when you flash the high beam.
) )
Comes on when the quantity of fuel left in the tank is 4 b. Besides the light coming on, after 2 Km, the multifunction LCD display shows the distance covered since the fuel reserve started being used. When the light comes on, refuel as soon as possible, see page 32 (FUEL). Continued X
