LOCATION OF INSTRUMENTS/CONTROLS
1
2
3
4
INSTRUMENTS AND INDICATORS
5
13
1
2
3
4
5
6
1 7
12
11
10
9
6
7
8
14 11
15
16
13
LOCATION OF INSTRUMENTS/CONTROLS - KEY 1) Clutch lever 2) Ignition switch / steering lock ( - - ) 3) Instruments and indicators 4) Front brake lever 5) Throttle grip 6) Hazard emergency push-button 7) ABS on/off switch (only for vehicles equipped with ABS) 8) Handgrips heating on/off switch ( OPT ) 9) Dimmer switch ( - ) 10)Display functions switch 11)High beam flasher - passing button 12)SET push-button 13)Starter button ( ) 14)Engine stop switch ( - ) 15)Horn button ( ) 16)Turn indicator switch ( ) 14
use and maintenance Breva
10
9
8
12
LOCATION OF INSTRUMENTS/CONTROLS - KEY 1) Green turn indicator warning light ( ) 2) Amber ABS light ( ) (Anti-lock Braking System) 3) Red alarm light 4) Green neutral light ( ) 5) Amber "stand down" light ( ) 6) Blue high beam warning light ( ) 7) Amber low fuel warning light ( ) 8) Multifunction digital display (Clock, ambient temperature, Odometer, trip data, Lap timer, alarm display, maintenance warning indicator) 9) Speedometer 10)Rev counter 11)Fuel level indicator 12)Red antitheft light 13)Red gear shift light ABS
