Lubrication Oil Engine Oil Refer table A for oil specifications. Other oils can be used if they meet minimum requirement of :
NOTE : Do not use diesel fuel with sulphur content more than 15 ppm.
- 15W40-CJ4 oil to be used. Selecting the Viscosity of Engine Oil (EO) During cold weather the selection of oil should be based on the coldest anticipated operating temperature to make starting easier. During hot weather, selection should be based on the highest anticipated operating temperature. When the prevailing temperature changes substantially, even though the regular intervals of lubricant change have not been reached, the lubricant must be changed. Refer Oil Specifications Chart for oil specifications at different range of ambient temperatures. Following oils of SAE grade 15W40 are recommended for temperature range of -150C to 500C with CJ4 API quality grade. 1. Citgo - Citgard 600 15W40. 2. ESSO - XD3 Extra CJ4. 3. Chevron - Delo 400 LE. 4. Mobil - Delvac Elite 15W40. 5. Shell - Rotella T3.
NOTE : It is not necessary to change the lubricant when the temperature enters into a different range during a working day, unless difficulty in starting is experienced. Change oil if the tractor is not used for 6 months.
6. Texaco - Ursa Premium TDS EC SAE15W40. Ambient temperature conditions in other range warrants other SAE grade of oil as per illustration.
PRECAUTIONS : After changing the oil, operate the engine at low speed without load, for at least 5 minutes. This will allow the oil to work into the bearings and onto the cylinder walls. *
3600 Series PST, TIER-4 Models - 3640 & 3650
Factory filled oil is 15W40-CJ4 and may change in future. From first Service onwards 15W40-CJ4 Oil to be used.
87
