Hydraulics & Transmission Hydraulic and Transmission Suction Oil Filter Change Hydraulics and Transmission oil filter (A) initially at 50 hrs. and subsequently at every 400 hrs. of operation. These Spin-on type filters are located behind on RH side of the tractor. Remove old spin-on filters. Prime the new spin-on filter with clean oil, and fit them.
Hydraulic and Transmission Strainer Clean suction strainer during every oil change. The suction strainer (B) is located on RH side of rear housing and can be removed as follows:
A
NOTE : The Hydraulic and Transmission filter though resembles with engine oil filter, it differs in construction and usage. Hence these are not interchangeable.
1) Remove suction filter of Hydraulic & Transmission. 2) Remove the cover plate by unscrewing four bolts. 3) Pull the suction strainer out from housing.
B
4) Clean the strainer in clean diesel fuel, using a soft brush, then blow dry with compressed air. 5) Refit the strainer. 6) Refit the cover plate and suction filter. For Service / Replacement of strainer contact your Mahindra Dealer.
Transmission Oil Drain Drain plug (C) is provided on the transmission for draining transmission oil. The drain plug located at the bottom of the transmission case.
C
3600 Series PST, TIER-4 Models - 3640 & 3650
83
