Controls Loader An easy option of connecting the loader valve is provided and the same can be connected as follows : 1. Remove the U-Tube (A) from elbows (B) and (C).
A
2. Connect pressure line of Loader valve to elbow (B). 3. Connect High Pressure Carry-Over line (HPCO) of Loader valve to elbow (C).
C
4. Remove the plug from adapter (D).
D
B
Connect tank line of Loader valve to adapter (D).
Opening the Hood Hood is hinged at rear side, near the fire wall (at junction of bonnet and firewall) and opens towards operator as follows: 1. Pull the knob (E). The hood will unlock. 2. Lift the hood upwards by hand. A gas spring provided inside will assist in minimising the effort for lifting. E
Closing the Hood 1. Ensure that side panels are properly locked. 2. Press the hood downwards till it gets locked.
48
3600 Series PST, TIER-4 Models - 3640 & 3650
