Switches 3. Alignment of Manual-mark with pointer - Operates Manual mode This switch can be used when the “PTO Engage - Disengage Switch” is in ON position. Keeping this switch in MANUAL-POSITION, will FORCE the PTO shaft rotation in RAISED as well as LOWERED position of implement. Even disengagement of clutch will not stop the PTO-SHAFT rotation. The “PTO Engage - Disengage Switch” will be CONTINUOUSLY-GLOWING when this switch is in MANUAL mode.
While the PTO is in MANUAL-MODE, some inadvertent movement of personnel near the PTO shaft can prove fatal. Key Pad Switch This Switch is snap fitted on LH side of steering column on dash board. This is provided for selecting digital display of indications like Hour counter, Hours for service due, Trip distance and Time Clock.
UP Key DOWN Key ENTER Key
POWER TAKE OFF PTO is operated electrically. PTO can be operated by using a combination of “PTO Engage - Disengage Switch” and “PTO Mode Switch”. After switching ON the “PTO Engage - Disengage Switch” the operator has a CHOICE to select AUTO or MANUAL MODE through “PTO Mode Switch”. The PTO will turn-Off if the “PTO Engage - Disengage Switch” or “PTO Mode Switch” is in OFF position. Refer table shown for combinations of PTO Operations.
40
PTO ON / OFF Switch ON
PTO Control Switch Manual Mode
ON
Auto Mode
ON
Auto Mode
Either pressed or released
ON
Auto Mode
Released
Clutch Pedal
PC Lever
PTO Switch
PTO Shaft
Either pressed or released Pressed
Either raised or lowered Either raised or lowered Raised
Glows
Rotates
Blinks
Stationary
Blinks
Stationary
Lowered
Glows
Rotates
3600 Series PST, TIER-4 Models - 3640 & 3650
