Instrument Cluster Parking Brake Indicator It glows when parking brake or foot brake pedals (latched together) is applied. Battery Charging Indicator This indicator will glow if battery is not getting charged. Once the engine is running, this indicator should go OFF, if the Battery is getting charged. If the indicator glows continuously even when the engine is running above low idle rpm of the engine, the cause should be investigated to prevent complete discharge of battery and possible damage of alternator. High Temperature Warning Indicator This is RED Led marked as "High Temp" and is located in the Temperature Gauge. It will glow continuously when temperature of coolant rised above 1100C. The pointer of Temperatur gauge will lie in the RED band under such condition. Low Oil Pressure Indicator This indicator when glows indicates the engine operation at low lub oil pressure. The indicator will also glow alone when the key is in ON position before starting the engine and continue to glow till engine oil pressure builds up after starting the engine. Water in Fuel Indicator This indication will be ON when the water is accumulated in the fuel filter. Air Filter Clog Indicator It is ON when air filter requires periodic maintenance. 4WD Indicator It glows when 4WD is engaged. CHK ENG (Check Engine) Indicator This indicator (E) will glow when the starter switch is turned to "ON" position. This indicator shall turn-off after engine is CRANKED. A malfunction other than Emission, such as Sensor failures would be indicated by a continuously "GLOWING" or "BLINKING" Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. MIL (Malfunction) Indicator This indicator (J) will glow when the starter switch is turned to "ON" position. This indicator shall turn-off after engine is CRANKED. A malfunction in the electronic emission control system (ECU) is indicated by a continuously "GLOWING" or "BLINKING" Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. 36
3600 Series PST, TIER-4 Models - 3640 & 3650
