TIRES/WHEELS/SPACING/BALLAST
TO ADJUST THE TOE-IN, USE THE FOLLOWING PROCEDURE: Adjust the rods to be equal the dimensions A on both side. 1. Loosen the lock nut at the rod end. 2. Turn the rod to shorten or lengthen the tie rod. 3. Lock the lock nuts. Tightening torque ……………………………………147 to 166 N-m(109 to 123Lbft)
LOCK NUT
BOLT
ROD
FILL HOLE
(RH SIDE) LOCK NUT
ROD
BOLT
LOCK NUT
ROD END
(RH SIDE)
A
75
16 Series, Model - 3316
