FIELD OPERATION
HYDRAULIC BLOCK A hydraulic block is located on the right side of the tractor. This block can provide an external hydraulic circuit for loader use or other applications. See your dealer. HYDRAULIC BLOCK
Rc1/4
PLUG 1
PLUG P
IMPORTANT: Never park a tractor with an implement in the raised position. Moving the
control lever forward will lower the implement even though the engine is not running. If it is necessary to service the implement in the raised position, use jack stands to safely block the implement in place. Put the hydraulic flow control knob in the LOCK position.
IMPORTANT:
Removing the Plug P when time that uses the loader and the hydraulic block. Installing plug 1 to the Rc1/4. (tightening torque 21to29N-m{15to21Lbft}) (Do not close the port in the hydraulic block when there is no plug 1 .) When Remote attachment is not installed, plug 1 is removed. Afterwards, please install Plug P. (tightening torque 49to58.8N-m{35to44 Lbft}) When the above is neglected, the hydraulic apparatus will be disadvantaged Plug 1 is made by the Loader manufacturer.
67
16 Series, Model - 3316
