FIELD OPERATION
Upper Link The length A of the upper link can be adjusted from 470 to 750 mm (18.5 to 29.5 inches).
UPPER LINK
TURNBUCKLE
Turn the turnbuckle clockwise to shorten the link or counterclockwise to lengthen the link.
HOOK
LOCK NUT
IMPORTANT: After the upper link is correctly adjusted, make sure the lock nut is tightened against the turnbuckle.
Stabilizer
B
LOCK PIN
SLIDER PLATE
When side movement of the hitch is undesirable or hazardous, the lateral swing is adjusted by select hole on the stabilizer. Slide REAR STABILIZER and adjust hole REAR and FRONT STABILIZER set clevis pin the hole.
I M P O R TA N T: A f t e r m a k i n g fi n a l
adjustments carefully raise the implement to make sure that there is proper clearance between the implement and tractor components.
NOTE: Insert pin to hole in clevis pin surely. IMPORTANT: When the implement is not
installing, adjusting to becoming dimension B=325mm(12.8inch) or more length of the stabilizer. Even if lower links shakes, it checks that it is not in contact with a tire. stabilizer may be changed or damaged if tire contacts lower links. 63
16 Series, Model - 3316
