FIELD OPERATION
HITCH SYSTEM ADJUSTMENTS The upper and lower links must be adjusted correctly so the implement can work at the needed depth and the links are free to move up and down with the shape of the ground.
UPPER LINK
LIFT LINKS
STABILIZERS
LOWER LINKS
Lift Links LOCK NUT
1. Connect the lift links to the tractor and TURN BUCKLE to the lower links. Make sure the lift links are installed on the proper Sides as shown. 2. The RH side lift link is adjustable by turnbuckle to obtain the desired position RH LIFT LINK of the hitch point. Turn the turnbuckle clockwise to shorten LH LIFT LINK the link or counterclockwise to lengthen the link. IMPORTANT: After the lift link is adjusted, make sure the locknut is tightened against the turnbuckle.
62
16 Series, Model - 3316
