FIELD OPERATION
CONNECTING IMPLEMENT TO DRAWBAR The correct connection of the implement to the drawbar will prevent stress on both the tractor and the implement. To assure proper tractor operation and optimum implement performance, the implement must be connected to the drawbar correctly. 1. Connect pull-behind implements to the drawbar only. 2. Use a hardened steel hitch pin to connect the implement to the drawbar. Make sure the pin is held securely in place with a lock pin. 3. When working with the drawbar, raise the lower links as high as possible to prevent interference between the lower links and the implement. REAR PTO SHAFT 4. The drawbar provides the standard hitch distance from the end of the PTO shaft to the centerline of the rear hole in the drawbar. This is necessary for safe PTO operation of trailing type equipment.
DRAWBAR
PTO RPM
PTO SHAFT DIAMETER
DIMENSION A
540
1.375 In (34.9 mm)
14 In (358 mm)
IMPORTANT: The maximum fixed drawbar vertical load is 440 kg(970 lbs)
59
16 Series, Model - 3316
