OPERATING/INSTRUCTIONS
POWER TAKEOFF (PTO):GEAR M i d P TO ( O P T I O N ) The Mid PTO has a 25.4 mm(1 inch) diameter 15 spline output shaft. ENGAGE THE MID PTO AS FOLLOWS: 1. Confirming disengage the clutch, pushing the PTO switch. 2. Turn right PTO switch to engage the PTO clutch. (turning the PTO shaft) 3. Move the Mid PTO control lever to the ON position.
PTO SWITCH
DISENGAGE THE MID PTO AS FOLLOWS: 1. Push the PTO switch to disengage the PTO clutch. (stop the turning of PTO shaft) 2. Move the Mid PTO control lever to the OFF (Engine Start) position.
NOTE: Keep the Mid PTO control lever in
the OFF (Engine Start) slot when starting the engine and when the PTO is not being used. The following table shows the required engine speed to get the required Mid PTO output shaft speed.
MID PTO LEVER
Push the PTO switch in the emergency. The rotation of PTO stops.
Mid PTO Output Shaft Speed
Required Engine Speed
2000 RPM
2525 RPM
54
16 Series, Model - 3316
