OPERATING/INSTRUCTIONS
POWER TAKEOFF (PTO):HST Mi d P TO ( O P T I O N ) The Mid PTO has a 25.4 mm(1 inch) diameter 15 spline output shaft. ENGAGE THE MID PTO AS FOLLOWS: 1. Push the clutch pedal fully. 2. Move the Mid PTO control lever to the ON position. 3. Release the clutch pedal slowly. DISENGAGE THE MID PTO AS FOLLOWS: 1. Push the clutch pedal fully. 2. Move the Mid PTO control lever to the OFF (Engine Start) position.
CLUTCH PEDAL
NOTE: Keep the Mid PTO control lever in
the OFF (Engine Start) slot when starting the engine and when the PTO is not being used.
MID PTO LEVER
3. Release the clutch pedal.
The following table shows the required engine speed to get the required Mid PTO output shaft speed. Mid PTO Output Shaft Speed
Required Engine Speed
2000 RPM
2525 RPM
53
16 Series, Model - 3316
