OPERATING/INSTRUCTIONS
POWER TAKEOFF (PTO):GEAR PTO driven machinery can cause serious injury or death, usually due to wrapped clothing. When required by the job to be in the drive shaft area, stay clear of rotating parts. Before working on the drive shaft, or servicing or clearing the driven machine, where applicable on this tractor, put the PTO clutch lever in the DISENGAGE position, the PTO lever in the NEUTRAL or OFF, and STOP the engine.
Re a r P TO The rear PTO is a 540 RPM with a 34.9 mm (1 3/8 inch) diameter 6 spline output shaft. ENGAGE THE REAR PTO AS FOLLOWS: 1. Confirming disengage the clutch, pushing the PTO switch. 2. Turn right PTO switch to engage the PTO clutch. (turning the PTO shaft) 3. Move the PTO control lever to the ON position.
REAR PTO SHAFT PTO SWITCH
DISENGAGE THE REAR PTO AS FOLLOWS: 1. Push the PTO switch to disengage the PTO clutch. (stop the turning of PTO shaft) 2. Move the PTO control lever to the OFF (Engine Start) position.
NOTE: Keep the PTO control lever in the
OFF (Engine Start) position when starting the engine and when the PTO is not being used. The following table shows the required speed to get the required Rear PTO output shaft speed. Push the PTO switch in the emergency. The rotation of PTO stops.
REAR PTO CONTROL LEVER
PTO Output Required Shaft Speed Engine Speed 540 RPM
52
2376 RPM
16 Series, Model - 3316
