OPERATING/INSTRUCTIONS
NORMAL STARTING PROCEDURE IMPORTANT: It is very important that enough lubricant reaches the engine parts before operating the engine at rated speed.
Operate controls only when seated in the operators seat.
Engine can start with transmission in gear when neutral or safety start switch is by-passed: 1. Do not connect across terminals on starter. 2. Attach a booster battery by connecting the positive terminal of the booster battery to the "positive terminal" provided or to the positive terminal of the machine battery. Connect the negative terminal of the booster battery to the chassis of the machine. Then use recommended starting procedures from operators seat. 3. When necessary, repair electrical system components promptly so that "jump starting" will not be attempted. Machine run-away can cause injury or death to operator and bystanders.
STEP 1
STEP 2
FUEL SHUT -OFF VALVE
NEUTRAL POSITION
OPEN
Make sure the fuel shut-off valve is open. The valve is located at the bottom RH side of the fuel tank.
Put the gear shift lever in the Neutral position (Gear Drive) or the Speed Lock Lever to be released (Hydrostatic Drive).
Before starting the engine, be sure all operating controls are in neutral or park lock position. This will eliminate accidental movement of the machine or start up of power driven equipment.
38
16 Series, Model - 3316
