ELECTRICAL SYSTEM
Line Fuse If the electrical circuit is accidently grounded or a reverse battery connection is made, the Line fuse located on the LH side of the engine will burn out and break the circuit to prevent to damage the solenoid switch, wiring harness and alternator charging system . If electrical problems occur, the Line fuse must be checked for continuity to determine if one of the circuits is broken, see your Dealer to replace and correct.
(1)50AMP (2)50AMP
NOTE:Exchange of the fuse is performed by opening the lid
(1) Protection of the main electrical machinery circuit (2) Protection of an ETR solenoid circuit
117
16 Series, Model - 3316
