LUBRICATION/FILTERS/FLUIDS
Transmission Oil Change Oil Change Interval…………………………………………………………………… Every 200 hours To change the transmission oil, use the following procedure: 1. Put the tractor on level ground, apply the park brake and stop the engine. Move the range shift lever to L position. 2.
TRANSMISSION DRAIN PLUG
Remove the drain plugs from the transmission case. (5 pieces)
NOTE:For best results, drain the oil when the oil is warm.
3.
R e p l a c e t h e h y d r a u l i c fi l t e r. S e e Hydraulic Filter in this manual.
TRANSMISSION DRAIN PLUG
4. For the hydrostatic drive tractor, replace hydrostatic filter, See Hydrostatic Filter (Hydrostatic Drive) in this manual. 5. Install the drain plugs with a seal washer and tighten to a torque of 39 to 44 N-m (29 to 33 Lbft).
FILL HOLE
6. Add the recommended oil through the fill hole and check the oil level.
GEAR DRIVE
7. Start the engine and check for leaks. 8. Recheck the oil level after stopping the engine. If the oil level is low, add oil up to the specified level.
FILL HOLE HYDROSTATIC DRIVE 103
16 Series, Model - 3316
