LUBRICATION/FILTERS/FLUIDS
TRANSMISSION & HYDRAULIC LUBRICATION Service Specifications Oil Level Check Interval…………………………………………………………………………… Daily Oil Change Interval…………………………………………………………………… Every 200 hours. Oil Capacity Gear Drive…………………………………….………… 30 Liters (31.7 Quarts). Hydrostatic Drive ……….……………………………… 31 Liters (32.7 Quarts). Oil Type Gear Drive………………………………HYDRAULIC TRANSMISSION FLUID Hydrostatic Drive……………………….HYDRAULIC TRANSMISSION FLUID Hydraulic System Check…………………………………………… Yearly inspect for leaks, cracks and abrasion. Tighten fittings or replace as needed. Transmission Oil Level
(Gear Drive)
To check the transmission fluid level, put the tractor on level ground. Unscrew the filler cap with dipstick and wipe it clean. Check fluid by dipstick level, Do not screw in cap when checking. If the fluid level is below the lower line of the dipstick, add the recommended fluid to raise the fluid level
DIP STICK
between the F (Full) and L(Low)marked position.
Transmission Oil Level (Hydrostatic Drive) Before checking the oil level of the hydrostatic drive tractor, run the engine for three to five minutes at 1500 RPM with the speed ratio control lever, range shift lever and PTO control lever in Neutral or OFF position. Then check the oil level in the transmission.
DIP STICK
To check the transmission oil level, put the tractor on level ground. Check the oil level on the transmission dipstick. If the oil level is below the lower line of the dipstick, add the recommended oil to the transmission to raise the oil level to the F (FULL) marked position. 102
16 Series, Model - 3316
